Wuxi FSK Transmission Bearing Co., Ltd fskbearing@hotmail.com 86-510-82713083
Rincian Produk
Tempat asal: Cina
Nama merek: FSK / NSK / NTN / NACHI / KOYO / FAG / OEM
Sertifikasi: ISO9001-2000 / CE / ROHS / UL / SGS
Nomor model: 51.208
Ketentuan Pembayaran & Pengiriman
Kuantitas min Order: 1 PC
Harga: Low Price
Kemasan rincian: 1) Coloured TUNGGAL BOX KEMASAN + CARTON BOX PACKING + palet, 2) KEMASAN INDUSTRIAL
Waktu pengiriman: 7 Hari Setelah Pesanan Dikonfirmasi
Syarat-syarat pembayaran: Deposit 30%, Saldo Setelah BL Copy
Menyediakan kemampuan: 100000pcs/bulan
Model No: |
51.208 |
Ukuran: |
40mm × 68mm × 19mm |
Berat badan: |
0,259kg |
Baris: |
Baris tunggal |
Ketentuan pembayaran bantalan ukuran inci: |
T / T, serikat barat, LC |
Pengiriman bantalan ukuran inci: |
Melalui laut atau udara, ekspres |
Model No: |
51.208 |
Ukuran: |
40mm × 68mm × 19mm |
Berat badan: |
0,259kg |
Baris: |
Baris tunggal |
Ketentuan pembayaran bantalan ukuran inci: |
T / T, serikat barat, LC |
Pengiriman bantalan ukuran inci: |
Melalui laut atau udara, ekspres |
Ukuran Kecil 51208, 8208 Thrust Ball Bearing, Single Row Gcr15
51000 Bearing Drawing
Gambar rinci bantalan
Seri R Miniatur Ball Bearing List
| BEARING NO | UKURAN | LOAD RATINGS | ||||||||
| Model Lama | d | D | B | rmin | CN dinamis | Statik CON | Lemak | Minyak | Massa / kg | |
| 51100 | 8100 | 10 | 24 | 9 | 0,3 | 7170 | 10.000 | 6000 | 8700 | 0,0192 |
| 51101 | 8101 | 12 | 26 | 9 | 0,3 | 7400 | 11000 | 5800 | 8300 | 0,0214 |
| 51102 | 8102 | 15 | 28 | 9 | 0,3 | 8100 | 13300 | 5600 | 8000 | 0,023 |
| 51103 | 8103 | 17 | 30 | 9 | 0,3 | 8300 | 14500 | 5400 | 7800 | 0,0251 |
| 51104 | 8104 | 20 | 35 | 10 | 0,3 | 11000 | 19600 | 4800 | 6900 | 0,037 |
| 51105 | 8105 | 25 | 42 | 11 | 0,6 | 11800 | 24200 | 4200 | 6000 | 0,0558 |
| 51106 | 8106 | 30 | 47 | 11 | 0,6 | 14200 | 31800 | 4000 | 5700 | 0,0602 |
| 51107 | 8107 | 35 | 52 | 12 | 0,6 | 15700 | 35500 | 3600 | 5200 | 0,072 |
| 51108 | 8108 | 40 | 60 | 13 | 0,6 | 20700 | 50000 | 3200 | 4700 | 0,115 |
| 51109 | 8109 | 45 | 65 | 14 | 0,6 | 21400 | 55000 | 3100 | 4450 | 0,141 |
| 51110 | 8110 | 50 | 70 | 14 | 0,6 | 20800 | 55000 | 2900 | 4200 | 0,152 |
| 51111 | 8111 | 55 | 78 | 16 | 0,6 | 31700 | 85900 | 2500 | 3700 | 0,227 |
| 51112 | 8112 | 60 | 85 | 17 | 1 | 31500 | 82100 | 2400 | 3400 | 0,276 |
| 51113 | 8113 | 65 | 90 | 18 | 1 | 35300 | 97800 | 2200 | 3200 | 0,32 |
| 51114 | 8114 | 70 | 95 | 18 | 1 | 36700 | 106700 | 2200 | 3100 | 0,344 |
| 51115 | 8115 | 75 | 100 | 19 | 1 | 37500 | 111100 | 2100 | 3000 | 0,385 |
| 51202 | 8202 | 15 | 32 | 12 | 0,6 | 12100 | 19400 | 4600 | 6600 | 0,045 |
| 51203 | 8203 | 17 | 35 | 12 | 0,6 | 13200 | 21700 | 4400 | 6300 | 0,051 |
| 51204 | 8204 | 20 | 40 | 14 | 0,6 | 16200 | 27500 | 3800 | 5500 | 0,076 |
| 51205 | 8205 | 25 | 47 | 15 | 0,6 | 21300 | 40100 | 3400 | 5000 | 0,109 |
| 51206 | 8206 | 30 | 52 | 16 | 0,6 | 21500 | 43200 | 3100 | 4500 | 0,132 |
| 51207 | 8207 | 35 | 62 | 18 | 1 | 30100 | 62200 | 2700 | 3900 | 0,215 |
| 51208 | 8208 | 40 | 68 | 19 | 1.1 | 34500 | 73000 | 2500 | 3600 | 0,259 |
| 51209 | 8209 | 45 | 73 | 20 | 1 | 36600 | 83400 | 2400 | 3400 | 0,302 |
| 52209 | 38209 | 35 | 73 | 37 | 1 | 36600 | 83400 | 2400 | 3400 | 0,609 |
| 51210 | 8210 | 50 | 78 | 22 | 1 | 41800 | 96800 | 2200 | 3100 | 0,371 |
| 52210 | 38210 | 40 | 78 | 39 | 1 | 41800 | 96800 | 2200 | 3100 | 0,716 |
| 51211 | 8211 | 55 | 90 | 25 | 1 | 53400 | 126000 | 1900 | 2700 | 0,587 |
| 52211 | 38211 | 45 | 90 | 45 | 1 | 53400 | 126000 | 1900 | 2700 | 1.1 |
| 51212 | 8212 | 60 | 95 | 26 | 1 | 56500 | 142000 | 1800 | 2700 | 0,671 |
| 51304 | 8304 | 20 | 47 | 18 | 1 | 23800 | 39600 | 3100 | 4500 | 0,146 |
| 51305 | 8305 | 25 | 52 | 18 | 1 | 27400 | 48900 | 2900 | 4200 | 0,168 |
| 52305 | 38305 | 20 | 52 | 34 | 1 | 27400 | 48900 | 2900 | 4200 | 0,33 |
| 51306 | 8306 | 30 | 60 | 21 | 1 | 36200 | 66500 | 2500 | 3700 | 0,258 |
| 52306 | 38306 | 25 | 60 | 38 | 1 | 36200 | 66500 | 2500 | 3700 | 0,48 |
| 51307 | 8307 | 35 | 68 | 24 | 1 | 43400 | 83300 | 2200 | 3200 | 0,37 |
| 52307 | 38307 | 30 | 68 | 44 | 1 | 43400 | 83300 | 2200 | 3200 | 0,519 |
| 51308 | 8308 | 40 | 78 | 26 | 1 | 53200 | 107000 | 2000 | 2900 | 0,52 |
| 52308 | 38308 | 30 | 78 | 49 | 1 | 53200 | 107000 | 2000 | 2900 | 1.01 |
| 51309 | 8309 | 45 | 85 | 28 | 1 | 58300 | 120000 | 1800 | 2700 | 0,685 |
| 52309 | 38309 | 35 | 85 | 52 | 1 | 58300 | 120000 | 1800 | 2700 | 1,24 |
Ukuran Kecil 51208, 8208 Thrust Ball Bearing Single Row Gcr15, Dapatkan Harga Ch eap dari China Ball Bearing Factory Sekarang!
Kontak Dengan Kami Secara Gratis
Wuxi FSK Transmisi Bantalan Co, Ltd
Alamat: No. 900 North Jie Fang Road
Distrik Chongan Wuxi Jiangsu Cina
Kontak: Kayee Fan
